Yamaha NMAX
YAMAHA / NMAX / SCOOTER
ENGINE
Type: Liquid-Cooled, 4-Stroke, SOHC, 4-Valve
Cylinders: Single Cylinder
Bore x Stroke: 58.0 x 58.7mm
Compression Ratio: 10.5 : 1
Maximum Horsepower: 11.1kW (8000rpm)
Maximum Torque: 14.4Nm (6000rpm)
Lubrication System: Force-Feed Lubrication, Wet Sump
Fuel System: Fuel Injection
Ignition System: TCI
Starting System: Electric Starter
Fuel Tank Capacity: 6.6 Litre
TRANSMISSION
Transmission Syatem: V-Belt Automatic
CHASIS
Overall Lenght: 1955mm
Overall Width: 740mm
Overall Height: 1115mm
Seat Height: 765mm
Wheelbase: 1350mm
Minimum: Ground Clearance 135mm
Weight (including full oil and fuel tank): 136kg
BRAKES
Front: Hydraulic Single Disc 230mm
Rear: Hydraulic Single Disc 230mm
SUSPENSION
Front Suspension Type: Telescopic
Rear Suspension Type: Unit Swing
TIRES
Front Tyre: 110/70-13
Rear Tyre: 130/70-13
